Maximize Solar Efficiency with Our Reliable BIPV Mounting System
The building integrated photovoltaic system represents a forward-thinking approach to sustainable building design. Compared with the traditional way of laying photovoltaic panels on a metal roof, the BIPV roofing attaches the mounting directly to the surface of the building without the need of metal roof laying. What you get: Save the full cost of metal roof materials and installation. One integrated PV mounting structure for roofing, waterproofing, and solar power. Optional translucent areas let natural light through while still generating electricity. One installation. Three functions. One cost.
Features of Integrated Solar Roofing Systems
Integrated Function
Integrates seamlessly into the building’s surface without separate metal roofing, the BIPV mounting system improves building aesthetic appeal and energy generation. Unlike traditional concrete tile roof solar mounting systems that sit on top of existing tiles.
Cost-effective
Designed with highly pre-assembled products and modular installation, the integrated solar roofing eliminates the need for separate metal roofing and reduces installation steps, lowering labor costs and being suitable for investment.
Flexible Application
The integrated solar metal roofing can be used for a variety of building types, from commercial and industrial facilities to residential projects. Its flexibility allows for easy integration in both new construction and renovation works.
Low Maintenance
Building integrated PV system is designed to require minimal maintenance throughout its service life. Its simple structure and durable materials reduce the need for frequent inspections or repairs, ensuring continuous and cost-efficient operation.
Specification of BIPV Roofing System
Applicable Components
Applicable Scenarios
Composition Accessories
Previous Cases
Framed PV modules, frameless PV modules
Economical installation for commercial or residential flat roofs and open areas
Poles, inclined beams, purlins, slant support, etc.
Jilin Project
Materials: Carbon steel mountings
Service life: 25 years
Maximum wind load: 1kN/m²
Maximum snow load: 1kN/m²
Foundation type: Cement pier+bolt
Angle: 15~30°
Coating: Hot-dip galvanizing treatment
BIPV Mounting FAQs
How is a BIPV system mainly installed?
A: There are two main ways: As a roof: It directly replaces the traditional metal roof, becoming the roof itself, generating electricity and providing waterproofing.
This integrated roofing system can also be used as a wall/skylight: As part of a curtain wall or skylight, it replaces ordinary glass, generating electricity while allowing light to pass through.
If I install BIPV (Building Integrated Photovoltaic), do I need to build another roof underneath?
A: No. Our integrated photovoltaic systems are a complete shell with built-in waterproofing, eliminating the need for an additional metal roof.
Can your building integrated photovoltaic system only be installed on roofs?
A: No. It can be installed on building facades (such as glass curtain walls) and atrium skylights, making the building itself a power generator.
